Maestro Fuzz-Tone FZ-M Guitar Effect Pedal

Maestro created the world’s first fuzz pedal - the Maestro Fuzz-Tone FZ-1 - the legendary sound on the Rolling Stones “(I Can’t Get No) Satisfaction.” Welcome to the FZ-M. This all-analog pedal boasts two-in-one functionality for increased sonic versatility with both an FZ-1 inspired fuzz sound and a thicker, more modern fuzz tone. Its 3-knob control layout gives you intuitive control. The Attack knob controls the
amount of fuzz. The Tone control lets you adjust the timbre from bright and raspy to warm and wooly and anywhere in between. Use the Level control to set the output volume; it can go way beyond unity gain when desired.

The true bypass footswitch triggers the LED lights in the bugles in the Maestro logo when it’s on, so you’ll always know when the effect is active.

Specs

Controls: Attack, Tone, Level
Switches: True Bypass footswitch, Modern/Classic Mode toggle switch
LED Indicators: Red, yellow, and blue bugles in the Maestro logo
illuminate when the pedal is active
Signal Processing: All-Analog
Power Requirements: 9V battery or regulated 9VDC power supply
(5.5 x 2.1 mm plug, wired center-negative)
Current Draw: 21 mA
Power On Switch: Incorporated into the input jack. Unplug the input when
not in use to prevent battery drain. Remove the battery when the pedal is
going to be stored for long periods to prevent leakage and damage.
Input Impedance: 32 kOhms
Output Impedance: 5 kOhms
Switching: True Bypass
Dimensions (D x W x H): 5.04” x 3.45” x 2.50” (128.0 mm x 87.6 mm x 63.5 mm)
Weight: Net 1.23 lb. (557.9 gm.), Gross 1.59 lb. (721.2 gm.)
SKU: MOCFTP
